Categories Humidity, Temperature & Humidity Transmitter
RHT-MOD Duct is a relative humidity transmitter with temperature output installed in air ventilation duct. Illuminated display ensures easy readability also from a distance. The RHT-MOD has a screwless lid and an easily adjustable mounting flange that make the installation of the device easy.
Brand : HK Instruments
| Attribute | Value |
|---|---|
| Product number | 1132240 |
| Communication | None |
| Power supply | 24 Vac/dc, < 1 VA |
| Humidity measurement range | 0…100 %rH |
| Humidity measurement accuracy | Typ. ±2 %rH (20…80 %rH), Max. ±3 %rH |
| Temperature measurement range | -50…50 °C |
| Temperature measurement accuracy | ±0.5 °C |
| Humidity output | 0…10 Vdc, 2 mA / 4…20 mA < 600 Ω |
| Temperature output | 0…10 Vdc, 2 mA / 4…20 mA < 600 Ω |
| Relay output | None |
| IP protection class | IP54 |
| IP protection class note | Cable or probe downwards |
| Cable gland | M16 |
| Ambient temperature | -50…50 °C |
| Mounting | With flange, probe depth adjustable < 150 mm |
| Materials | PBT and stainless steel |
| EAN13 | 6419767001498 |
