RHT-MOD Duct

      Categories Humidity, Temperature & Humidity Transmitter

      Humidity transmitters with temperature output for duct that use Modbus serial communication protocol

      RHT-MOD Duct is a relative humidity transmitter with temperature output installed in air ventilation duct. In addition to these measured values, RHT-MOD Duct calculates various parameters such as dew point, mixing ratio, enthalpy and absolute humidity. Illuminated display ensures easy readability also from a distance. The RHT-MOD has a screwless lid and an easily adjustable mounting flange that make the installation of the device easy.

      Brand : HK Instruments

      Get Quote
      • Description

        RHT-MOD Duct series devices include

      • Separate Modbus output for all measured and calculated parameters (relative humidity, temperature, dew point, mixing ratio, enthalpy and absolute humidity).
      • Offset feature enabling field calibration for measurement parameters rH and T.
      • Mounting flange
      • Clear backlit display

      Technical Details

      Communication RS-485 Modbus (RTU)
      Accuracy Temperature: <0.5 °C
      Relative humidity: ±2…3 % rH at 0…50 °C and 10…90 % rH
      Total error band includes accuracy, hysteresis and temperature effect over 5...50 °C and 10–90 % rH
      Measuring units °C, % rH
      Measurement elements NTC10k temperature sensor, thermoset polymer capacitive sensing element for humidity
      Supply voltage 24 VDC/VAC ±10 %
      Current consumption max 90 mA (at 24 V) + 10 mA for each voltage output
      Operating temperature 0...+50 °C
      Protection standard IP54

      RHT-MOD Duct
