Differential Pressure Transmitter - Dual – TWO PRESSURE SENSORS

Categories Pressure, AIR

Differential Pressure Transmitter - Dual series differential pressure transmitters are engineered for building automation in the HVAC/R industry. Differential Pressure Transmitter - Dual is a technologically advanced transmitter measuring static and differential pressure from two different points, with field selectable units, range and output, all in a single device.

Differential Pressure Transmitter - Dual series devices include

Multiple measurement units, field selectable via jumper, including: inWC, mmWC, Pa, mbar.
8 field selectable measurement ranges, unidirectional or bi-directional, selectable via jumper.

Brand : HK Instruments

Get Quote

Description
Attachment

Accuracy (from applied pressure) (model 2500)	Pressure < 125 Pa = 1 % + ±2 Pa Pressure > 125 Pa = 1 % + ±1 Pa
Accuracy (from applied pressure) (model 7000)	Pressure < 125 Pa = 1.5 % + ±2 Pa Pressure > 125 Pa = 1.5 % + ±1 Pa
Zero point calibration	by pushbutton
Measuring units	Pa, kPa, mbar, inchWC, mmWC
Supply voltage	24 VDC ±10% / 24 VAC ±10%
Power consumption	< 1.0 W
Output signals (3-wire)	2 x 0…10 VDC or 2 x 0…5 VDC (selectable by jumper)
Operating temperature	-20…+50 °C
Response time	0.8 / 4 s
Protection standard	IP54
