Differential Pressure Transmitter - Dual-MOD – TWO PRESSURE SENSORS AND MODBUS COMMUNICATION

Categories Pressure, AIR

Field adjustable differential pressure transmitter with two pressure sensors for air and an Input terminal for two analog inputs for external signal conversion into Modbus.

Differential Pressure Transmitter-Dual-MOD combines two differential pressure transmitters into one device. It offers a possibility to measure pressure from two different points. It has a Modbus interface and an Input terminal. When using the Input terminal, temperature transmitters can be replaced with temperature sensors. As a result you will save in costs of the devices and in the installation costs. The AHU model that includes an air flow transmitter has been designed especially for ventilation units.

Brand : HK Instruments

Get Quote

Description
Attachment

Differential Pressure Transmitter-Dual-MOD series devices include

Multiple measurement units, field selectable via menu, including: Pa, mbar, inchWC, mmWC and psi.
Input terminal enabling reading of multiple other signals such as temperature or control relays over Modbus

Communication	RS-485 Modbus (RTU)
Accuracy (from applied pressure) (model 2500)	Pressure < 125 Pa = 1 % + ±2 Pa Pressure > 125 Pa = 1 % + ±1 Pa
Accuracy (from applied pressure) (model 7000)	Pressure < 125 Pa = 1.5 % + ±2 Pa Pressure > 125 Pa = 1.5 % + ±1 Pa
Zero point calibration	via Modbus or by pushbutton
Measuring units	Pressure: Pa, kPa, mbar, inchWC, mmWC, psi Flow: (AHU model) m³/s, m³/hr, cfm, l/s, m/s, ft/min
Supply voltage	24 VDC ±10 % / 24 VAC ±10 %
Power consumption	< 1.3 W
Operating temperature	-10…+50 °C
Response time	1…20 s selectable via menu
Protection standard	IP54

Differential Pressure Transmitter Dual Mode

DPT-Dual_MOD_Series_Datasheet-6.0

Download

DPT-Dual-MOD-Series_Manual-6.0.pdf

Download
