Differential Pressure Transmitter Priima MOD – HIGH ACCURACY, WITH MODBUS COMMUNICATION

Categories Pressure, AIR

High accuracy transmitter with Modbus communication and air flow measurement

Differential Pressure Transmitter-Priima-MOD is a multifunctional high accuracy differential pressure transmitter with Modbus communication and air flow measurement. It is designed for cleanrooms and other demanding applications. Differential Pressure Transmitter-Priima-MOD has a new, extremely accurate sensor and automatic zero point calibration, and optional calibration certificate.

Brand : HK Instruments

Get Quote

Description
Attachment

The Differential Pressure Transmitter-Priima-MOD is used for measuring differential pressure and air flow in building automation, HVAC and cleanroom systems. It can also be used with several different measurement probes such as FloXact™ or pitot tube, and air dampers. The most common applications are pressure monitoring in cleanrooms and over the building envelope.

Technical Data

Communication	RS-485 Modbus (RTU)
Accuracy (from applied pressure)	0.4 % + ±0.4 Pa
Measuring ranges (Pa)	-120…+120 / -240…+240 / -620…+620 / -1240…+1240 / -2490…+2490
Zero point calibration	automatic with autozero element (-AZ), by pushbutton or via Modbus
Measuring units	Pressure: Pa, kPa, mbar, inchWC, mmWC, psi Flow: m³/s, m³/h, cfm, l/s, m/s, ft/min
Supply voltage	24 VDC ±10 % / 24 VAC ±10 %
Power consumption	< 1.0 W
Output signal	via Modbus
Operating temperature	-5…+50 °C
Response time	0.4–20 s
Protection standard	IP54

Differential Pressure Transmitter-PRIIMA-MOD

DPT-Priima-MOD_Series_Datasheet-1.0
