DPT-Flow is a flow transmitter that provides a new and easy way to measure the flow rate on centrifugal fans.
One device is suitable for a range of different fan types. It also provides an easy way to measure flow rate in a duct system. The device is supplied with an optional FloXactTM averaging measurement probe.
Brand : HK Instruments
The DPT-Flow is designed for air handling units to measure the air flow on centrifugal fans. The DPT-Flow can be used as an on-site display for flow or as a transmitter to regulate the air flow on a selected fan or blower.
The DPT-Flow can also be used in the duct system or in air handling units as an on-site display for flow or as a transmitter to regulate the air flow in a duct. The device can be used with several different measurement probes such as FloXactTM or pitot tube, and air dampers. The requirement is that the K-value of the measurement probe or damper is known.
| Accuracy (from applied pressure) (models 1000 and 2000) |
Pressure < 125 Pa = 1 % + ±2 Pa Pressure > 125 Pa = 1 % + ±1 Pa |
| Accuracy (from applied pressure) (models 5000 and 7000) |
Pressure < 125 Pa = 1.5 % + ±2 Pa Pressure > 125 Pa = 1.5 % + ±1 Pa |
| Zero point calibration | automatic with autozero element (-AZ) or by pushbutton |
| Measuring units | Pressure: Pa, kPa, mbar, inchWC, mmWC, psi Flow: m3/s, m3/hr, cfm, l/s, m/s, ft/min |
| Supply voltage | 24 VAC ±10 % / 24 VDC ±10 % |
| Power consumption | < 1,0 W |
| Output signals for pressure and air flow (selectable by jumper) | 0…10 VDC / 2…10 VDC 4…20 mA |
| Operating temperature | -20…+50 °C (with autozero calibration -5…+50 °C) -40…+50 °C (-40C model) |
| Response time | 1…20 s |
| Protection standard | IP54 |
