Siro - MOD

      Categories IAQ Sensors, Indoor Air Quality Transmitter

      Multifunctional indoor air quality transmitters for building automation systems that use Modbus serial communication protocol

      Siro-MOD is an indoor air quality transmitter with a modern design. The transmitter is available with several optional air quality sensors. The modular device can be equipped with CO2 concentration and VOC (Volatile Organic Compounds) measurements or alternatively PM (Particulate Matter) measurement, and in addition, temperature and humidity measurements. It offers easy installation and adjustment, several different model options and various output signals that are configurable separately for each measurement parameter.

      Brand : HK Instruments

      Get Quote
      • Description
      • Attachment

      The Siro-MOD series devices are available with a user interface that includes an LCD display and buttons making the configuration of the device quick and easy. An external configuration tool is necessary for commissioning preparations for Siro-MOD without the user interface. Configuration is also possible via Modbus network. Siro-MOD utilizes the industry standard NDIR measurement principle with self-calibrating ABC logicTM for CO2 measurement.

        Siro-MOD series devices include

      • Several options for indoor air quality measurements (CO2, VOC, PM, rH, T).
      • Field configurable outputs for selected measurements.
      • Proportional output options including voltage (0–10 V, 0–5 V, 2–10 V) and optional current (4–20 mA).
      • Offset feature enabling field calibration for each measurement parameter (CO2, VOC, PM, rH, T).
      • Optional LCD-display and buttons.

      Technical Data

      Communication: RS-485 Modbus (RTU)
      Accuracy:
      		 CO₂: ±40 ppm + 3 % of reading (typical),
      additional ±60 ppm for first weeks
      Relative humidity: ±2.2 % rH (typical at 20 °C, 30 % rH)
      Temperature: ±0.4 °C (typical at 20 °C)
      VOC: ±15 % of reading (typical)
      *VOC sensor is tuned for typical IAQ Mix of 22 VOCs as defined by Mølhave et al. (1997)
      PM:
      0…100 μg/m3:
      PM2.5: ±15 μg/m3(at 25 ⁰C ±5 ⁰C)
      PM1/PM10*: ±25 μg/m3 (at 25 ⁰C ±5 ⁰C)
      100…1000 μg/m3:
      PM2.5: ±15 % (at 25 ⁰C ±5 ⁰C)
      PM1/PM10*: ±25 % (at 25 ⁰C ±5 ⁰C)
      *PM1 and PM10 values are calculated from PM2.5 measurement reading with the default particle distribution.
      Measuring elements: CO2: Non-dispersive infrared (NDIR)
      VOC: Complementary Metal Oxide Semiconductor (CMOS)
      PM: Laser-based light scattering particle sensing
      Temperature: Integrated to CMOS
      Relative humidity: Thermoset polymer capacitive sensing element
      Measuring units: CO2: ppm
      Relative humidity: % rH
      Temperature: °C
      VOC CO2eq: ppm
      TVOC: ppm, μg/m3
      PM1/2.5/10: μg/m3
      Calibration (CO2): Automatic self-calibration, ABC LogicTM
      Supply voltage: 24 VDC/VAC ±10 %
      Output signal 1–4: 0...10 V (optional 2...10 V / 0...5 V, display or configuration tool required)
      Optional 4...20 mA
      Linear to selected measurement (CO2, VOC, PM, rH or Temp)
      Operating temperature: 0...50 °C
      Protection standard: IP20
