Categories Liquid & Gas Analysis, Turbidity Sensor
EXpure 191 is a highly accurate compact NIR turbidity sensor for monitoring processes with very low turbidity, e.g. in water applications. It is well suited for swimming pool applications, as well as for some special measuring points in the drinking water sector. The measuring principle used is a 90° scattered light measurement.
Brand : Exner
| Measuring range max. | 0...10 NTU |
| Resolution | 0,01 NTU |
| Accuracy | ± 1 % from final value |
| Reproducibility | ≤ 1 % from final value |
| Light source | LED |
| Optical unit | Stainless steel (1.4435) |
| Windows | Sapphire |
| Sealing | EPDM |
| Flow-through cell | Plastic (PE-HD black) |
| Supply voltage | 24 V DC |
| Process connection | Thread G1/4" |
| Process temperature | 1...50 °C |
| Process pressure | 0...6 bar |
| Electrical connection | Connector 8-pin (IP68K) |
| Interfaces | RS485 Modbus, 0/4...20 mA |
| Parameterisation | Software EXpert |
| Flow rate | 30...80 l/h |
| Protection class | IP65 |
